Mobile Line for
UV Liner Production
Produce UV liners independently:
control quality, reduce costs, and eliminate delays
Unique compact technology
for UV liner production
Compact production line.
With the ability to scale production volumes.
High profitability.
Cost reduction of up to 70%
with in-house
UV liner production for rehabilitation
– sizes and timelines will always be guaranteed accurate, because now you produce the liner yourself for your specific needs.
Technical specifications
The line is equipped with advanced systems for precise resin dosing, temperature and pressure control, allowing for the production of liners with high accuracy and quality.
Length: 20000 mm
Width: 3060 mm
Height: 3100 mm
Electrical power: 400 V, 50 Hz
Power consumption: 20 kW
Compressed air: 6 bar, 1000 l/min
Overall ventilation system: 20-60 m³/s
Local ventilation system (optional): 3-10 m³/s
Room specifications
The equipment is placed in a facility with optimal conditions, ensuring uninterrupted production of high-quality UV liners.
Length: at least 35 m
Width: at least 18 m
Height: at least 4 m
Free space around the machine: 1.5 m
Gate dimensions: 3×4 m Access for oversized transport
General uniform lighting: 300 lux
Allowable floor slope: 0.2%
Raw material and finished product storage area: 20 slots (pallet size 1150x1150x1500 mm) In a 2-level shelving system
Temperature: 20°C
Humidity: 75%
Production technology
The equipment is placed in a facility with optimal conditions, ensuring uninterrupted production of high-quality UV liners.
– cutting films
– resin preparation
– glass impregnation
Diameter range
Components for manufacturing
While other contractors wait for the ordered liner to be manufactured, you are already rehabilitating the damaged pipeline
Line start-up —
within 1 month from the equipment delivery
You receive the equipment, a list of material suppliers, an initial batch of raw materials, and staff training to stay ahead of competitors and take your business to the next level.
MSK Liner – a unique technology
with 10 years of experience
Our company started the pipeline rehabilitation business with a UV Liners in 2017. During our work, we encountered many problems related to the supply of the main material: UV Liner. Constant price fluctuations, logistical difficulties, production time, and so on, forced us to think about producing our own UV Liners.
We designed and manufactured a line to make our own UV Liners. Since 2021, we produce and use only our own UV Liners for rehabilitation. This 2021 year has become the year of our independence and rapid development of our business.
The profitability of our business has doubled, downtime associated with logistics has disappeared, and our competitors have been left behind. No company can still compete with us in terms of price, turnaround time and quality. And all this because we do not depend on UV Liners suppliers; we produce it ourselves when necessary, as much as necessary. We set our own prices and monitor quality.
Progress does not stand, and we decided that it was time to take the rehabilitation market to a new level. Let every installer have the opportunity to produce his own UV Liner. Let him regulate the price, terms, sizes, etc. For this purpose, we designed and began manufacturing commercial lines for the UV Liner production. The commercial version has compact size, modular design, only high-quality components from famous world brands and meets international quality and safety standards.
We ready to share our experience and supply equipment that will make you the undisputed market leader. Become the first and only one in your market.
Отзывы
Do you have any questions?
If you cannot find the answer, contact us, and we will be happy to help.
Do you provide spare parts in case of a breakdown?
How many people are needed to operate the equipment?
Can I store materials for liners without additional costs for special storage conditions?
Is additional equipment adjustment required for different diameters?
How often does the equipment need maintenance? Is there a maintenance plan?
What materials and documentation are provided for working with the equipment?
Technical documentation — instructions for operation, setup, and maintenance of the equipment.
1. A list of consumables required for liner production, suppliers, and material requirements for finding alternatives.
2. Safety instructions — recommendations for safe operation with equipment and materials.
3. Technological process of production — precise guidelines for resin mixing and fiberglass use to achieve optimal UV liner quality.
The complete set of documentation helps quickly and safely master the equipment and begin its efficient operation in the shortest possible time.
Is it possible to scale up production if I need increased output?
